Gas Detection with Electrochemical Cells

Substance / Sensor Sensor Part-No Nominal Range Comments

AsH3 Arsine (3 El.) 9602-6001 0 ... 1.00 ppm

AsH3  Arsine (2 El.) 9602-6000 0 ... 1.00  ppm special application

AsH3 Arsine (2 El.) 9602-6002 0 ... 10.0 ppm special application

B2H6  Diborane 9602-6200 0 ... 1.00  ppm

Br2  Bromine 9602-6800 0 ... 5.00 ppm

Cl2  Chlorine 9602-5300 0 ... 5.00 ppm

ClF3 Chlorine Trifluoride 9602-7410 0 ... 1.00 ppm

ClO2 Chlorine Dioxide 9602-7400 0 ... 1.00 ppm

CO  Carbon Monoxide 9602-5400 0 ... 500 ppm

COCl2  Phosgene 9602-6600 0 ... 1.00 ppm

F2  Fluorine 9602-6400 0 ... 5.00 ppm

GeH4 Germane 9602-6900 0 ... 5.0 ppm

H2  Hydrogen (1%) 9602-5100 0 ... 1.000 % vol.

H2  Hydrogen (4%) 9602-5101 0 ... 4.00 % vol. special range

H2S  Hydrogen Sulphide 9602-5200 0 ... 100 ppm

H2S  Hydrogen Sulphide (org.) 9602-5201 0 ... 30.0 ppm special application

H2Se Hydrogen Selenide 9602-5600 0.00 ...5.00 ppm

HBr  Hydrogen Bromide 9602-7000 0 ... 30.0 ppm

HCl  Hydrogen Chloride 9602-5800 0 ... 30.0 ppm

HCN  Hydrogen Cyanide 9602-5700 0 ... 30.0 ppm

HF  Hydrogen Fluoride 9602-6500 0 ... 10.0 ppm

HMDS Hexamethyldisilazane 9602-6715 0 ... 0.500 % vol.

HMDS Hexamethyldisilazane 9602-6714 0 ... 500 ppm

N2H4 Hydrazine 9602-7600 0 ... 1.00 ppm

NH3  Ammonia 100ppm 9602-6704 0 ... 100 ppm Standard

NH3 Ammonia 1000ppm 9602-6705 0 ... 1000 ppm Standard, for higher range

NO  Nitric Oxide 9602-7200 0 ... 250 ppm

NO2  Nitrogen Dioxide 9602-7300 0 ... 25.0 ppm

O2  Oxygen 9602-5500 0 ... 25.0  % vol.

O3  Ozone 9602-7100 0 ... 1.00 ppm

O3  Ozone 9602-7101 0 ... 1.00 ppm Exhaust monitoring

PH3  Phosphine (2 El.) 9602-6100 0 ... 1.00  ppm special application

PH3  Phosphine (3 El.) 9602-6101 0 ... 1.00  ppm

SiH4 Silane 9602-6300 0 ... 50.0 ppm

SO2  Sulphur Dioxide 9602-5900 0 ... 25.0 ppm

TEOS Tetraethyl Silicate 9602-7500 0 ... 100 ppm

TMB Trimethyl Borate 9602-7510 0 ... 200 ppm

TMP Trimethyl Phosphite 9602-7800 0 ... 30.0 pp

CH4 Methane 9602-9900 0 ... 100 LEL for Satellite C only /Standard

CH4 Methane 9602-9901 0 ... 100 LEL for Satellite C only

CH4 Methane 9602-9902 0 ... 100 LEL for Sat-Ex C Version

CH4 Methane 9602-9903 0 ... 100 LEL for Sat-Ex C Version

CH4 Methane 9602-9905 0 ... 100 LEL for Sat-Ex C Version

C4F6 Hexafluoro-1,3-butadiene 9602-9732  0.....50.0  ppm

C5F8 Octafluorocyclopentene 9602-9730  0 ... 20.0  ppm

CH3F Methyl Fluoride 9602-9720  0 ... 0.500  % vol.

DCE 1,2 Di-chloro-ethylene 1,2 9602-9600  0 ... 1000 ppm

NF3 Nitrogen Trifluoride 9602-9700  0 ... 50.0  ppm

SF6 Sulphur Hexafluoride 9602-9710  0 ... 0.500  % vol.
